Sustainable Energy

Blue Hydrogen

ProMax 6.0 is a great choice for simulating the various Blue Hydrogen production options which often include Carbon Capture, Utilization, and Storage (CCUS).

Relevant reacting systems below can be modeled using ProMax:

  • Steam Methane Reforming with Flue Gas CO2 Capture
  • Autothermal Reforming
  • Pre-reforming
  • Tri-reforming

Green Hydrogen

With ProMax 6.0, BR&E introduces new process blocks for simulating water electrolysis to produce Green Hydrogen:

  • Polymer Electrolyte Membrane (PEM)
  • Alkaline Water Electrolysis (AWE)
  • Solid Oxide Electrolysis (SOE)

Many alternate combinations of properties available for solving the electrolyzer including:

  • Total Power Input
  • Hydrogen Production Target
  • Fraction Inlet H2O Conversion
  • Current Density
  • Area per Cell
  • Cells per Stack
  • Stacks per Facility
